Model: OHZ43X
Type: SquareFlange
Flange Standard: custom against client's reouirement
Face to Face: MSS SP-81
Testing Standard: API-598
Operation: handwheel, electric, pneumatic, hydraulicsprocket, electro-hydraulic, gear, lever
SHORT INTRODUCTION
Main material: O235, Stainless steel
Wedge material: F55, F53, 2205, S5310, S5316L, SS316, SS304
Sealing material: NBR, FKM, graphite, Metal to Metal, EPDM, Graphite
Packing: Aramid fiber, high-water based fiber, rubber PTFE, graphite
Applicable medium: Applicable for Urban sewage treatment, sugar Dowder chemical and other fields
