Model: QCGZ43H+PU
Working Pressure: DN50-DN200 63bar
DN250-DN400 40bar
DN450-DN600 25bar
Type: Flance
Design Standard: MSS SP 8
Flange Standard: DIN PN1D, PNI6 150LB, JIS 10K, TABLE E/D
SHORT INTRODUCTION
Face to Face, Nss Sp.s
Testing Standard: APi 598
Operation handwheel, electric pneumatic, hydraulic, gear
Main material: WCB, WCC CF8, CFSM, CF3M
Wedge material: SS304, SS316L, F53.F55, 2205
Sealing material: H-PTFE-PU
Packing: graphite
Applicable medium: Pulp, oil, gas
